GE Proteus 46-155400G46 / 46-155318G33 Imaging Tube DOM: 10-2018

GE Proteus MX100 09PS High-Performance Imaging Tube (DOM: 2018)

The GE 46-155400G46 (MX100 09PS) is a premium, rotating-anode X-ray tube assembly engineered for the demanding workflow of GE Proteus and Definium radiography systems. This unit features the MX-100 insert (Part #2336058), renowned for its excellent thermal capacity and consistent output during heavy-duty orthopedic and general radiographic procedures.

With a dual focal spot of 0.6 mm / 1.25 mm, this tube provides the versatility required for both high-detail extremity imaging and high-power abdominal or chest studies. Manufactured in October 2018, this tube is a "late-model" harvested component, offering a reliable and cost-effective alternative for clinical environments seeking to restore their GE Rad-Room to peak performance.

Key Features

• Manufacturer: GE Healthcare

• Model Numbers: 46-155400G46 / 46-155318G33

• Insert Model: MX100 09PS (Insert #2336058)

• Date of Manufacture (DOM): October 2018

• Focal Spots: 0.6 mm (Fine) / 1.25 mm (Large)

• Power Rating: 40–100 kW

• Serial Number: 104964TY2

Clinical & Operational Advantages

• Dose-Efficient Precision: Optimized for use with GE’s auto-collimation and phototiming systems, ensuring high-quality diagnostic images with minimized patient dose.

• Broad GE Compatibility: Beyond the Proteus XR/a, this tube is compatible with various GE imaging platforms, including the Definium 8000, Discovery, and Revolution XRD (verification by system serial number recommended).

• APR Ready: Fully supports Anatomic Programmed Radiography (APR) workflows, allowing for rapid, pre-programmed exposure settings that improve technologist efficiency.

• Superior Thermal Management: The MX100 housing is designed for rapid cooling, reducing the wait time between exposures in high-volume trauma or outpatient settings.

Condition

• Status: Used – Harvested System Subcomponent.

• Extraction Note: This tube was professionally extracted from an overhead Proteus Rad-Room system by experienced technicians. It was handled with extreme care to protect the high-voltage receptacles and oil-filled housing.

• Functional Assessment: Being sold as a "Tested Functional" part. While the tube was performing within OEM specifications at the time of removal, the buyer is responsible for performing a professional "Seasoning" (warm-up) procedure and vacuum integrity check by a certified physicist or biomedical engineer prior to clinical use.

Warranty

• ✔ Primis "Integrity-First" Guarantee We guarantee the tube will arrive free of oil leaks and physical housing damage. Due to the sensitive nature of X-ray vacuum inserts, Primis Medical recommends installation by a qualified GE-trained technician to ensure proper calibration and system handshake.

What’s Included

• (1) GE Proteus MX100 09PS Imaging Tube Assembly (46-155400G46)

Shipping

• Professional Freight Handling: This item contains dielectric oil and a fragile glass/metal insert. It will be crated or double-boxed with specialized shock-absorbing materials.

• Ships within 1-2 business days.
