Image Diagnostics Aspect 100R Motorized C-Arm Imaging Procedure Table DOM: 12/04

Image Diagnostics Aspect 100R Motorized C-Arm Imaging Procedure Table DOM: 12/04

• Model: Aspect 100R
• S/N: 6 05/044
• Date of Manufacture: 12/04
• Tabletop Dimensions (standard): 24″ × 80″
• Optional tabletop Dimensions: 22″ × 80″ (w/ facial cut‑out)
• Motorized Elevation: approx. 28.5″ to 40″ (tabletop to floor height)
• Lateral Roll: ± 20°
• Weight Capacity: 450 lbs.
• Table Weight: approx. 395 lbs.
• Power: 120 VAC standard, 230 VAC optional; internal battery back‑up operation
• Top Construction: Carbon‑fiber tabletop with very low x‑ray attenuation for excellent fluoroscopic image quality
• Base: Slim‑profile long wheel base, locking swivel casters for easy maneuverability and stability
• Warranty: 90 Days

Elevate your imaging suite with the state‑of‑the‑art Aspect 100R Motorized C‑Arm Imaging Table from Image Diagnostics, engineered for maximum precision, efficiency and radiographic clarity. Built around a carbon‑fiber tabletop that offers minimal x‑ray attenuation, this table delivers exceptional fluoroscopic image quality and extensive unobstructed imaging area (62″/157 cm), allowing clinicians complete C‑arm access and freedom of positioning for interventional and general imaging procedures.

With motorized elevation from approximately 28.5″ to 40″ (72–102 cm) and a full ±20° lateral roll feature, the Aspect 100R supports seamless patient positioning, multi‑angle imaging and enhanced ergonomics for procedural staff. The 24″ × 80″ (61 × 203 cm) standard tabletop (or optional 22″ × 80″ with facial cut‑out) accommodates a wide spectrum of patient sizes while maintaining a robust 450 lb (204 kg) capacity — ensuring true clinical versatility and patient safety.

Designed for real‐world workflow and maintenance ease, its slim‑profile pedestal base with locking swivel casters provides excellent mobility without compromising stability. The internal battery back‑up ensures uninterrupted operation even during power fluctuations, while the sleek, easy‑to‑clean design promotes infection control in busy procedural environments. Rugged, reliable and purpose‑built for modern imaging suites, the Aspect 100R delivers performance, flexibility and image quality — all in one premium mobile table solution.

This medical equipment item is being sold in its current condition, with only a basic assessment performed. It powers up and successfully completes its self-check or boot process, indicating that it is operational to that extent. However, no further testing beyond this initial check has been conducted.
