Pajunk SonoPlex II 001287-74 Echogenic Nerve Block Needle - 22G x 50mm, Facet S Tip BX/10

Pajunk SonoPlex® II | Dual Guidance | 22G x 50 mm | 001287-74

The Pajunk SonoPlex® II (001287-74) represents the 2026 gold standard for Peripheral Nerve Blocks (PNB). Engineered for Dual Guidance, this needle allows clinicians to simultaneously utilize ultrasound visualization and nerve stimulation. By integrating laser-embossed Cornerstone Reflectors, Pajunk has solved the clinical challenge of "needle dropout," ensuring the shaft and tip remain highly visible even at the steep insertion angles required for deep-seated neural structures.

Featuring the Facet S tip and NanoLine® coating, the SonoPlex II provides a superior tactile "pop" while maintaining a smooth, atraumatic glide through various tissue layers.

Key Performance Features

• Cornerstone Reflectors: Laser-etched graduations around the full 360° of the needle ensure high echogenicity. These reflectors are specifically engineered to return ultrasound waves to the transducer even at steep angles (up to 60° or 70°).

• Facet S Tip Geometry: A hybrid design that combines the sharpness of a facet needle for effortless skin entry with a specialized bevel angle that enhances tactile feedback and provides a clear "click" when penetrating the fascia.

• NanoLine® Thin-Film Coating: An ultra-thin polymer coating that provides exceptional insulation for precise nerve stimulation while reducing friction during insertion, ensuring the needle doesn't "drag" on the tissue.

• Dual Guidance Integration: Includes an integrated stimulation cable and injection tubing, allowing for a seamless transition between ultrasound identification and electrical nerve localization.

• Removable Stimulation Cable: Features a standardized connector compatible with all major nerve stimulators, allowing for easy disconnection if stimulation is no longer required during the block.

Technical Specifications

• Manufacturer: Pajunk (Made in Germany)

• Product Code: 001287-74 (SonoPlex® II)

• Gauge: 22G

• Length: 50 mm (2 inches)

• Tip Style: Facet S (Echogenic)

• Coating: NanoLine® (Insulated)

• Connection: Integrated Tubing and Stimulation Lead

• Quantity: Box of 10 individual needles

Clinical & Institutional Advantages

• Increased Safety: Dual Guidance reduces the risk of accidental intraneural injection by providing two independent methods of verifying needle-to-nerve proximity.

• Reduced Procedure Time: Superior echogenicity at all angles minimizes the need for "probing" or transducer adjustments, allowing for faster block placement.

• Institutional Standardization: Sourcing genuine Pajunk overstock allows high-volume anesthesia departments to utilize the most advanced echogenic technology while maintaining strict budgetary controls.

Ideal Applications

• Upper Extremity Blocks: Interscalene, supraclavicular, and axillary blocks.

• Lower Extremity Blocks: Femoral and saphenous nerve blocks.

• Chronic Pain Management: Targeted diagnostic injections and therapeutic blocks under ultrasound.

Condition & Quality Assurance

• Status: NEW — Genuine Pajunk Overstock.

• Expiration Date: Typically May 2030 (05-2030).

• Packaging: Original OEM packaging with factory seals 100% intact.

• Verification: Guaranteed authentic Pajunk instrumentation, stored in a climate-controlled environment to preserve the integrity of the NanoLine® coating and sterile tubing.
