Synthes 200.807 1.5mm Cortex Screw Self-tapping 7mm

Synthes 1.5mm Cortex Screw | Self-Tapping | 7mm Length | 200.807

The Synthes 200.807 is a high-precision micro-fixation implant engineered for secure anchorage in dense cortical bone. As a 1.5mm diameter screw with a shallow 7mm length, it is a foundational component of the Synthes Modular Hand and CMF (Craniomaxillofacial) systems. This screw is designed to provide stable fixation for small bone fragments where larger hardware would be obstructive or risk further comminution of the fracture site.

The self-tapping distal tip features precision-machined cutting flutes, allowing the screw to be advanced into a $1.1\text{mm}$ pilot hole without the need for a separate tapping step. This ensures a high-tolerance interface with the bone while significantly reducing operative time in delicate reconstructive procedures.

Key Specifications

• Manufacturer: Synthes (DePuy Synthes)

• Model / REF: 200.807

• Material: 316L Stainless Steel (Surgical Grade)

• Screw Diameter: 1.5 mm

• Thread Profile: Self-Tapping / Fully Threaded

• Screw Length: 7 mm

• Core Diameter: 1.1 mm

• Head Diameter: 3.0 mm

• Thread Pitch: 0.5 mm

• Drive Type: Cruciform Recess

• Quantity: Individually Packaged (Non-Sterile)

Technical & Clinical Advantages

• Micro-Scale Precision: The $0.5\text{mm}$ thread pitch provides a high thread-density, maximizing pull-out resistance in the thin, dense cortical layers of the hand or facial skeleton.

• Self-Tapping Efficiency: The integrated cutting flutes reduce insertion torque and eliminate the need for manual tapping. This is particularly advantageous in fragile micro-fragments where excessive mechanical stress could jeopardize fragment alignment.

• Low-Profile Head Design: With a $3.0\text{mm}$ head diameter, this screw is designed to sit flush within the counter-sunk holes of Synthes DCP (Dynamic Compression Plate) and LC-DCP (Limited Contact) systems, as well as Modular Hand Systems, reducing the risk of palpable hardware or soft-tissue irritation.

• Biomechanical Integrity: Forged from cold-worked 316L stainless steel, the 200.807 offers the high fatigue resistance necessary to maintain stable fixation throughout the biological stages of bone healing.

Applications

• Hand & Wrist Surgery: Fixation of phalangeal fractures, metacarpal head fragments, and small-bone osteotomies where a short $7\text{mm}$ reach is required.

• Craniomaxillofacial (CMF) Surgery: Stabilization of midface fractures, orbital rim repairs, and thin bone-graft fixations.

• Pediatric Trauma: Fixation of small bone injuries where avoiding neurovascular structures or growth plates is critical.

• Modular Plating: Fully compatible with Synthes $1.5\text{mm}$ modular micro-plating sets.

Condition & Quality Assurance

• Status: NEW — Original Manufacturer's Packaging.

• Integrity: This implant is new. As a non-sterile component, it must be inspected for thread integrity and processed through a validated sterilization cycle (typically steam autoclaving) in accordance with hospital protocols and Synthes IFU (Instructions for Use) prior to clinical use in 2026.

• Professional Standards: With over 25 years of experience in surgical hardware, Primis Medical ensures all micro-fragment implants are maintained in optimal conditions to preserve the mechanical and sterile integrity of the system.

Shipping & Handling

• Secure Logistics: Shipped in protective, padded packaging to ensure the precision-machined $1.5\text{mm}$ threads and cruciform recess remain pristine.

• Fast Dispatch: Ships within 1 business day.
