Waldmann TRIANGO LED 60-3 C Minor Procedure Light, 60,000 lux/1 M, color change - 3700K, 4300K and 4700K, CRI>93, dimming. With ceiling mount.

Waldmann TRIANGO 60 | 60,000 Lux | Compact Minor Procedure Light

The Waldmann TRIANGO 60 is the most compact model in the TRIANGO medical series, specifically engineered for the high-frequency daily routine of family practices, outpatient clinics, and specialty departments. Delivering 60,000 lux at 1 meter, it provides a high-intensity, homogeneous light field that excels in Gynecology, Dermatology, and Veterinary Medicine.

With its minimalist design and Diamond Optics, the TRIANGO 60 ensures high-contrast visualization while occupying a minimal footprint in the procedure room.

Key Specifications

• Manufacturer: Waldmann (Derungs)

• Model: TRIANGO 60

• Light Intensity: 60,000 Lux at 1 meter

• Color Temperature: Fixed 4700 K (or optional adjustable 3700K/4300K/4700K)

• Dimming: Continuous (Infinitely dimmable via membrane keypad)

• Illumination Field: Fixed 7-inch (18 cm) or focusable up to 11-inch (28 cm)

Technical & Clinical Advantages

• Infinitely Dimmable Control: Unlike lights with fixed percentage steps, the TRIANGO 60 features a continuous dimming interface. This allows clinicians to adjust the intensity to the exact level required for the procedure, effectively eliminating glare on metallic instruments and reducing eye strain.

• Diamond Cluster Optics: This specialized lens technology creates a crisp, wide lighting field. The standard 18 cm diameter ensures focused illumination for localized procedures, while the focusable option allows for expansion up to 28 cm for larger surface areas.

• Compact Minimalist Design: The slim, aerodynamic housing is ideal for smaller exam rooms. Its smooth, seamless construction simplifies the infection control process, allowing for rapid and thorough disinfection with standard medical wipes.

• Balanced Spring Articulation: The arm system is engineered for effortless movement and precise "stay-put" stability. The spring-balanced joints allow the practitioner to position the light with one hand, ensuring it remains drift-free during delicate maneuvers.

• Energy Efficiency: Consuming less than 30W, the TRIANGO 60 is an environmentally conscious and cost-effective solution for facilities with high patient volumes, requiring no bulb changes throughout its long LED lifespan.

Available Configurations

The TRIANGO 60 is a modular system that can be ordered in several mounting and functional formats:

• Mounting Versions: Available in Ceiling Mount, Wall Mount, or Mobile Floor Stand.

• Optical Options: Fixed field (18 cm) or Focusable field (18 / 23 / 28 cm).

• Color Options: Fixed high-contrast 4700K or 3-step adjustable color temperature.

Ideal Applications

• Primary Care & General Practice: Versatile illumination for wound care, suturing, and physical exams.

• Dermatology: High-contrast light for identifying lesions and performing biopsies.

• Gynecology & Urology: Clear visualization for diagnostic exams and minor outpatient procedures.

• Veterinary Clinics: A compact, reliable solution for exam tables and dental bays.

Condition & Quality Assurance

• Status: NEW — Factory Direct Quality.

• Integrity: Includes the light head with membrane keypad, articulated spring arm, and choice of mounting hardware.

• Protection: Rated IP 43 for protection against dust and splashing liquids.

• Standards Compliance: Fully compliant with EN 60601-1 and EN 60601-2-41 for medical electrical equipment safety and performance.

Shipping & Handling

• Secure Logistics: Shipped in specialized reinforced packaging to ensure the precision optics and spring calibration remain in perfect alignment.

• Fast Dispatch: Typically ships within 1–2 business days.
